Step-by-Step Process to Make Toughened Safety Glass

How your cat flap singe glazed or double glazed unit for your window or Door

Glass Cutting and Preparation

• The glass is first cut to its final size and shape from standard float glass.
• All edges are smoothed or polished to prevent stress points, as toughened glass cannot be cut or altered after tempering.

Washing and Inspection

• The glass is thoroughly washed to remove dust, oil, or debris that could cause defects.
• It's then inspected for any surface flaws, chips, or cracks.

Heating in a Tempering Furnace

• The clean glass enters a tempering furnace, where it's heated to around 620–680°C (about 1148–1256°F) — just below its softening point.

Rapid Cooling (Quenching)

• The heated glass is then rapidly cooled using high-pressure blasts of air from multiple nozzles.
• This rapid cooling (quenching) takes just a few seconds and cools the surface much faster than the interior.

Stress Formation

• This cooling process creates compressive stress on the surface and tensile stress inside the glass.
• These internal stresses are what give toughened glass its increased strength and shatter-resistant properties.

Quality Testing (Optional)

• Some manufacturers test samples for strength, optical quality, and fragmentation behavior (how it breaks under force).



Key Benefits of Toughened Safety Glass

• 4–5x stronger than regular float glass
• Breaks into small blunt fragments (reducing injury risk)
• Heat-resistant and impact-resistant
• Complies with BS EN 12150 and BS 6206 (UK standards)

Important Notes

Cannot be cut, drilled, or reshaped after tempering — all alterations must be done beforehand.
If the glass is damaged during tempering or has impurities, it may spontaneously shatter (rare, but preventable with heat soak testing).
